Specifications:
Excitation light:
Semiconductor laser
Laser color:
Full color
Laser wavelength:
Blue 447 nm
Laser power:
500 mw, 1000 mw
Spot diameter
4mm
Scanning system:
High-speed vibroscope; Scanning Angle ±30 degrees, scanning speed 40K; Input signal ±5V.
Linearity 99.9%, distortion < 2%; The response time is 250s.
Control system:
ILDA DB25 interface; DMX512 interface; Automatically; Support central control
American Pangolin professional laser control software
Safety items:
Lightning protection; Rain; Constant temperature (-40℃ ~ 50℃); Overvoltage and overcurrent protection
Application:
Bar, nightclub, DISCO, KTV room, theater, etc
Cooling method:
Air cooling
Power supply/power consumption:
AC110V/220V; 50-60HZ/100W
Product:
W146mm x H252mm x D106mm
Weight:
< 2.5 Kgs
Photometric:
Illustrations:
Product Size:
Accessaries:
Video:
